The VTC Weigh Feeder is ideal for continuous operation or burst operations where accurate volume or weight control of feeders is required. Compact, robust and reliable, the VTC Weigh Feeder is an excellent choice for a wide range of bulk solids applications. Designed for maximum efficiency and productivity, its unique design offers many advantages over traditional bulk solids processing methods; such as easy access to product supply and control, low wastage, and improved quality due to reduced product blending.
Very Sturdy and Rugged Frame Design.Quick Belt change mechanism ensures very low downtime.Designed capacity upto 400 TPH.Unique Dual Load cell design for accurate weighing.Feed control inputs from Driving as well as Driven pulleys to ensure Precise feed rate..Accuracy : ± 0.5% SD on the set point. Pre Feeder For Powder Elements| Capacity | 0.05 to 20 TPH |
|---|---|
| Belt Width | 500 to 1800 mm wide |
| Control Range | 1:10 |
| Infeed Hopper | Designed as per material characteristics |
| Liners | Optional |
| Weight Sensing | By dual loadcell weighing mechanism |
| Speed Sensing | Digital Taco meter |
| Type of motors | AC 3-phase |
| Drive Mechanism | Direct coupled shaft-mounted drives |
| Speed Control | AC Variable Speed Drive / DC thyristor drive |
| Electronic Controller | Dedicated Controller |
| Accuracy | ± 0.5% SD on the set point in the control range |
| Model | VEC |
|---|---|
| Type | Micro-Controlled based |
| Housing | Aluminium Extruded |
| Display | Graphics LCD with LED |
| Front Keypad | Membrane foil with pressure sensitive keypad |
| Operating Temperature | 0oC to 50oC |
| Digital Inputs | 12 Nos. Expandable to 16 |
| Digital Outputs | 12 Nos. Expandable to 16 optically isolated |
| Analog Inputs | 2 Nos. isolated (4-20 mA optically isolated) |
| Analog Output | 2 Nos. isolated |
| Serial Interface | RS232/RS485/Profibus Connectivity |
The weigh feeder system is equipped with an Operator panel, which helps with the visualization of tasks.
The Controller can be configured to communicate with various Industry specific information systems. These interfaces are tested and certified to perform in a harsh industrial environment including excessive shock, high temperature, and continuous operation. Communicating with a variety of weighing systems is made simple with our ultra-reliable Ethernet interface or RS232 port.
Prompt customer service with a call away. With after-sales support being the cornerstone of our business philosophy, we offer prompt and efficient after-sales service.
Our Electronic controller ensures a trouble-free interface with the plant's processes and control system.Specially developed software offers seamless integration with PLC or PC.Belt load.Belt speed.Measured rate.Totalized quantity.
